Combination Tail Lamp. 3853 Series. Diffused Tail Light with Sequential Indicator. ECE Approved. Multi-Volt 12-24v. 5 Year Warranty. Twin Pack. Left & Right Hand Side Plus Load Resistor. 3853ARWM-2-LR

3853 Series Rear Combination Lights.

Diffused Tail Light Function with Sequential Indicator.

ECE/ADR Approved. Multi-Volt 12-24v.

Stop, Tail, Indicator and Reverse.

Twin Pack, Left x 1 and Right Hand Side x 1, Plus Load Resistor Included, 12v x 2

3853ARWM-2-LR.

Genuine Autolamp Product. Genuine Authorised Dealer.

Genuine Warranty Backup. Genuine Australian Company.

Genuine ADR or ECE Approval.

Not Made in China.

Specifications	3853ARWM-2-LR
Input Voltage	12v & 24 Volt DC
Lamp Functions	Stop, Tail, Indicator and Reverse
Lens Colour	Clear
LED Colour	Red, White and Amber
Current Draw Amps	Stop - 0.11a @ 12v, 0.06a @ 24v Tail - 0.39a @ 12v, 0.20a @ 24v Ind - 0.16 @ 12v, 0.09a @ 24v Rev - 0.20a @ 12v, 0.10a @ 24v
Dimensions	387 x 105 x 30.5mm
Mounting Type	Surface Mount

Cable Length	40cm
Warranty	5 Year
Approvals	ECE Stop/Tail E97R02/272389300 ECE Indicator E96R01/292389300 ECE Reverse E923R00/2223893*00

Load resistor may be required, Part Number - BR122
